제품 설명
UV wavelength information
-UV-V : 230~395nm (Peak 360nm)
-UV-A : 230~370nm (Peak 360nm)
-UV-B : 220~320nm (Peak 305nm)
-UV-C : 220~280nm (Peak 265nm)
-Visible Blue(VBL) : 300~470nm (Peak 405nm)
-Visible Green(VGR) : 300~510nm (Peak 385nm)
- Features
-
- AlGaInN-based UV sensor
- Optical fiber
- Fiber length : Standard 1m(±10cm), customized length is available
- Applications
-
- UV curing
- UV lamp/LED monitoring
- Specifications
-
- Power supply : DC 6~26 V or DC 9 ~ 26 V
- Ourput: DC voltage(0~5V) or DC current(4~20 mA)
- Operating temp.: ~ 200 C
